A mobile concrete plant, also known as a portable concrete plant, is a type of concrete mixing plant that is designed to be easily transported from one location to another. It typically consists of a mixing system, batching system, and control system mounted on a trailer or a semi-trailer. As a mobile concrete batching plant manufacturer in India, our company prides itself on producing state-of-the-art equipment that meets the needs of the modern construction industry. With years of experience and a commitment to innovation, we have become a trusted provider of high-quality mobile concrete plants. Whether you are looking to complete a large commercial project or a small construction project, mobile concrete plants are designed to be easily transportable andhighly efficient in energy saving, making them an ideal solution for any construction site.
Mobile concrete plants are commonly used for construction projects that require temporary concrete production, such as road construction, bridge building, and remote site construction. They are also used in situations where the cost of transporting ready-mix concrete to a site is prohibitively high or where a continuous supply of fresh concrete is required. Manufacturer of mobile concrete batching plant in Mumbai, Delhi, Pune, Bangalore, Gujarat, Hyderabad, Uttar Pradesh, Assam, Sikkim, Odisha, Nagpur, India.
The main advantages of portable concrete batching plants are their flexibility and mobility. They can be easily transported to the construction site and set up quickly, which makes them ideal for short-term projects or projects that require frequent relocation.
一个底盘提供了优异的耐久性,放松of travel, quick installation, and continuous long-life operation, all of which contribute to more accurate weighing when vibrations are minimized. Other advantages include longer product life and shorter installation times.
| MODEL | MGI MBP-20 | MGI MBP-30 | MGI MBP-40 | MGI MBP-60 |
|---|---|---|---|---|
| BATHCING CAPACITY | 15 m³/h | 30 m³/h | 45 m³/h | 60 m³/h |
| HOPPERS | 2 X 2 | 2 X 2 | 2 X 2 | 2 X 2 |
| MIXER | Reverse Drum | Reverse Drum | PAN TYPE | PAN TYPE |
| BATCH CAPACITY | 0.35 M³ | 0.5 CU.M | 0.75 CU.M | 1.0 CU.M |
| Length | 6800mm | 7900mm | 8900mm | 11000mm |
| Width | 2500mm | 3100mm | 3800mm | 4200mm |
| CEMENT BIN | 1 TONS | 1.5 TONS | 2 TONS | 2 TONS |
| DISCHARGE MECHANISH | Reverse Drum/4Mtrs. Pan Mix | |||
| POWER REQUIRED | 29 HP | 35 HP | 48 HP | 55 HP |
| Price mini mobile batching plant | Rs. 13,50,000/- | Rs. 22,50,000/- | Rs. 28,50,000/- | Rs. 37,50,000/- |
| POWER SUPPLY | 415 V, 50 Hz, 3 PHASE, A.C. | |||
Features and Components of a Compact Concrete Plant
- Sand and gravel are often kept in hoppers or cross bins that measure 2 x 2. On each Hopper are gates that are opened and closed using pneumatic actuators. Gravel and sand weighing conveyor with four electronic load cells are suspended from the ceiling. On top of the sand, the Hopper is a bin vibratory motor that has been fitted.
- A charge conveyor that makes use of rubber belts is used to feed the aggregates and sand that have been previously weighed into the equipment that is known as a Stationary Concrete Batching Plant – Pan Mixer.
- It is a heavy-duty steel pan type mixer with a wear-resistant replacement liner plate that is 10 millimeters thick and spring-loaded paddle mixer arms with replaceable blades. In a Pan Mixer, a gate that is operated hydraulically can be installed so that the concrete mixture can be discharged more quickly. Pan Mixer Pan The mixing arm is powered using a planetary Gear Box in conjunction with a motor.
- A submersible pump and the related pipelines bring water from the storage tank to the mixer, where it is mixed. The PLC is responsible for managing the amount of water consumed throughout each cycle or batch. By dosing water and gravel simultaneously, it is feasible to cut down on cycle time and abrasion caused by the Pan Mixer (aggregates). In addition to providing top-notch equipment, we also offer excellent customer service and support. Our compact concrete plant supplier India team is always available to answer your questions and provide guidance throughout the purchasing process. Whether you need help selecting the right equipment for your project or have questions about installation and maintenance, we are here to help.
- A cement weigher that is outfitted with an independent load cell is used to complete the task of weighing the cement. Cement is stored in a hopper attached to the frame of an infeed charging conveyor. The cement must be delivered to the cement weigher, and the Screw Conveyor is responsible for making that happen.
Cost Benefits of a Mobile Concrete Batching Plant
- Available in 15m3/ 20 m3/ 40 m3 / 60 m 3hr. Capacity.
- Reversible non-tilting drum type concrete mixer with (Hopper).
- Compact design for easy of transportations & shifting by towing also.
- Plant can be erected & commissioned within hours.
- Complete plant can be transported in one 26 feet trailer.
- Specially carbon steel casted gear ring & roller, so the machines show high mechanical performance.
- Includes printout USB system.
- Fully automatic plant with electronic weighing of Agg. / sand/ water/ cement.
- Chemical additive system.
- Belt conveyor for aggregate & sand loading.
- Conveyor belt for transit mixer loading.
- Single Chassis for durability and transportation ease.
- Mobile Type concrete batching plant offers cost benefits like no other batching plant and range of
- Mobile batching plant price starts from Rs. 14,00,000/- while mini batching plant range starts from Rs. 10,00,000/-.
- Available in 4 and 5 bin configuration.
Mobile Concrete Batching Plant Manufacturer Dubai, UAE, NEPAL, AFRICA, INDIA
As a mobile concrete plant manufacturer, our company prides itself on producing state-of-the-art equipment that meets the needs of the modern construction industry. With years of experience and a commitment to innovation, we have become a trusted provider of high-quality mobile concrete plants. Whether you are looking to complete a large commercial project or a small residential job, our mobile concrete plants are designed to be easily transportable and highly efficient, making them an ideal solution for any construction site.
一个世界级的移动混凝土厂制造facility that uses the latest technology and top-quality materials to create equipment that can withstand the rigors of construction. We understand the importance of having reliable equipment on the job site, which is why we are dedicated to producing concrete plants that are durable, efficient, and built to last. A team of experts work tirelessly to ensure that each mobile concrete plant we produce meets the highest standards of quality and performance.
When you work with a small mobile concrete plant manufacturer, you can stay assured that you are getting the best possible equipment for your needs. A team of skilled technicians will work with you to ensure that your mobile concrete plant is customized to meet your specific requirements. We take pride in our ability to provide personalized service to our clients and are committed to helping you achieve your construction goals with a range of mini mobile batching plant for sale.
In addition to providing top-notch equipment, we also offer excellent customer service and support. The mobile concrete plant manufacturer team is always available to answer your questions and provide guidance throughout the purchasing process. Whether you need help selecting the right equipment for your project or have questions about installation and maintenance, we are here to help.
In conclusion, if you are in need of a high-quality mobile concrete plant, look no further than our mobile concrete plant manufacturer. We are dedicated to providing exceptional equipment, personalized service, and expert support to help you achieve your construction goals.
If you are looking for Low cost and best quality Mini Concrete Batching Plant Manufacturer in India then contact Maan Global Industries for best prices of Concrete Ready mixers.
